TI的4通道,14位,105MSPS 模数转换器IC ADS6444IRGCT
信息类型:供应
TI 主页 > 半导体 > 数据转换器 > 模数转换器 > 高速 ADC (>10MSPS) >
4-channel, 14-bit, 105MSPS Analog-to-Digital Converter
4通道,14位,105MSPS 模数转换器IC ADS6444IRGCT
4通道,14位,105MSPS 模数转换器IC ADS6444IRGCT的说明
The ADS6445/ADS6444/ADS6443/ADS6442 (ADS644X) is a family of high performance 14-bit 125/105/80/65 MSPS quad channel A-D converters. Serial LVDS data outputs reduce the number of interface lines, resulting in a compact 64-pin QFN package (9 mm × 9 mm) that allows for high system integration density. The device includes 3.5dB coarse gain option that can be used to improve SFDR performance with little degradation in SNR. In addition to the coarse gain, fine gain options also exist, programmable in 1dB steps up to 6dB.
The output interface is 2-wire, where each ADC data is serialized and output over two LVDS pairs. This makes it possible to halve the serial data rate (compared to a 1-wire interface) and restrict it to less than 1Gbps easing receiver design.
4通道,14位,105MSPS 模数转换器IC ADS6444IRGCT的特性
Maximum Sample Rate: 125 MSPS
14-Bit Resolution with No Missing Codes
Simultaneous Sample and Hold
3.5dB Coarse Gain and up to 6dB Programmable Fine Gain for SFDR/SNR Trade-Off
Serialized LVDS Outputs with Programmable Internal Termination Option
Supports Sine, LVCMOS, LVPECL, LVDS Clock Inputs and Amplitude down to 400 mVPP
Internal Reference with External Reference Support
No External Decoupling Required for References
3.3-V Analog and Digital Supply
64 QFN Package (9 mm × 9 mm)
Pin Compatible 12-Bit Family (ADS642X - SLAS532A)
Feature Compatible Dual Channel Family (ADS624X - SLAS542A, ADS644X - SLAS543A)
APPLICATIONS
Base-Station IF Receivers
Diversity Receivers
Medical Imaging
Test Equipment
4通道,14位,105MSPS 模数转换器IC ADS6444IRGCT的应用
基站 IF 接收器
多样性接收器
医学影像
测试设备
TI 主页 > 半导体 > 数据转换器 > 模数转换器 > 高速 ADC (>10MSPS) >
4-channel, 14-bit, 105MSPS Analog-to-Digital Converter
4通道,14位,105MSPS 模数转换器IC ADS6444IRGCT
4通道,14位,105MSPS 模数转换器IC ADS6444IRGCT的说明
The ADS6445/ADS6444/ADS6443/ADS6442 (ADS644X) is a family of high performance 14-bit 125/105/80/65 MSPS quad channel A-D converters. Serial LVDS data outputs reduce the number of interface lines, resulting in a compact 64-pin QFN package (9 mm × 9 mm) that allows for high system integration density. The device includes 3.5dB coarse gain option that can be used to improve SFDR performance with little degradation in SNR. In addition to the coarse gain, fine gain options also exist, programmable in 1dB steps up to 6dB.
The output interface is 2-wire, where each ADC data is serialized and output over two LVDS pairs. This makes it possible to halve the serial data rate (compared to a 1-wire interface) and restrict it to less than 1Gbps easing receiver design.
4通道,14位,105MSPS 模数转换器IC ADS6444IRGCT的特性
Maximum Sample Rate: 125 MSPS
14-Bit Resolution with No Missing Codes
Simultaneous Sample and Hold
3.5dB Coarse Gain and up to 6dB Programmable Fine Gain for SFDR/SNR Trade-Off
Serialized LVDS Outputs with Programmable Internal Termination Option
Supports Sine, LVCMOS, LVPECL, LVDS Clock Inputs and Amplitude down to 400 mVPP
Internal Reference with External Reference Support
No External Decoupling Required for References
3.3-V Analog and Digital Supply
64 QFN Package (9 mm × 9 mm)
Pin Compatible 12-Bit Family (ADS642X - SLAS532A)
Feature Compatible Dual Channel Family (ADS624X - SLAS542A, ADS644X - SLAS543A)
APPLICATIONS
Base-Station IF Receivers
Diversity Receivers
Medical Imaging
Test Equipment
4通道,14位,105MSPS 模数转换器IC ADS6444IRGCT的应用
基站 IF 接收器
多样性接收器
医学影像
测试设备
