用于电机控制或太阳能微型转换器的隔离放大器IC AMC1200SDUBR
删除信息打印此文 发布时间:2019/5/24 18:55:42 | 人查看
信息类型:供应

用于电机控制或太阳能微型转换器的隔离放大器IC AMC1200SDUB 和 AMC1200BDUB
半导体 > 数据转换器 > 模数转换器 > 隔离式 ADC > 用于并联测量的 4kV 峰值隔离放大器
Fully-Differential Isolation Amplifier

AMC1200SDU的说明
The AMC1200 is a precision isolation amplifier with an output separated from the input circuitry by a silicon dioxide (SiO2) barrier that is highly resistant to magnetic interference. This barrier has been certified to provide galvanic isolation of up to 4000 VPEAK according to UL1577 and IEC60747-5-2. Used in conjunction with isolated power supplies, this device prevents noise currents on a high common-mode voltage line from entering the local ground and interfering with or damaging sensitive circuitry.
The input of the AMC1200 is optimized for direct connection to shunt resistors or other low voltage level signal sources. The excellent performance of the device supports accurate current control resulting in system-level power saving and, especially in motor-control applications, lower torque ripple. The common-mode voltage of the output signal is automatically adjusted to either the 3-V or 5-V low-side supply.
The AMC1200 is fully specified over the extended industrial temperature range of –40 °C to +105 °C and is available in the SMD-type, gullwing-8 package

AMC1200SDU的特性
±250-mV Input Voltage Range Optimized for Shunt Resistors
Very Low Nonlinearity: 0.075% max at 5 V
Low Offset Error: 1.5 mV max
Low Noise: 3.1 mVRMS typ
Low High-Side Supply Current: 8 mA max at
5 V
Input Bandwidth: 60 kHz min
Fixed Gain: 8 (0.5% accuracy)
High Common-Mode Rejection Ratio: 108 dB
3.3-V Operation on Low-Side
Certified Galvanic Isolation:
UL1577 and IEC60747-5-2 Approved
Isolation Voltage: 4000 VPEAK
Working Voltage: 1200 VPEAK
Transient Immunity: 10 kV/μs min
Typical 10-Year Lifespan at Rated Working Voltage (see Application Report SLLA197)
Fully Specified Over the Extended Industrial Temperature Range

APPLICATIONS AMC1200SDU的应用
Shunt Resistor Based Current Sensing in:
Motor Control
Green Energy
Frequency Inverters
Uninterruptible Power Supplies
相关应用产品
EV HEV 充电器:1 级和 2 级
EV HEV 充电器:3 级
太阳能反向器
太阳能微型逆变器
太阳能微转换器/DC-DC 电源优化器

深圳市鹏展翅电子有限公司(pzcdz),主营TI/BB/NS/ADI品牌全新原装IC,公司团队专注于TI品牌原装进口集成电路10多年,现货多多,TI/BB系列很多型号具有价格优势,可全线订货。鹏展翅网站 http://pzcdz.ic.net.cn 电话: 0755-32918091/13713594500 QQ:957010014 微信:dujunjie0755 ​
用于电机控制或太阳能微型转换器的隔离放大器IC AMC1200SDUBR

用于电机控制或太阳能微型转换器的隔离放大器IC AMC1200SDUBR
